IPS e.max® Monolithic



At ROE, IPS e.max monolithic crowns represent one of our three primary monolithic options, delivering 530MPa flexural strength, making it a strong restoration option suitable for most patient cases.

The IPS e.max provides translucency that closely mimics natural tooth structure while requiring minimal preparation to preserve valuable tooth structure, delivering excellent biocompatibility and predictable outcomes for crowns, inlays, onlays, and veneers.

We accept both conventional PVS impressions and digital scans from all major systems, offering model-free fabrication with turnaround times of three days for digital submissions and four days for digitized PVS impressions.

This combination of superior strength, natural esthetics, and streamlined workflow makes IPS e.max an ideal lower-cost solution for single-unit cases where both durability and esthetics are essential.
e.max Monolithic Hero
e.max Monolithic Overview@0.25x

Clinical Benefits of an IPS e.max crown



  • Superior Strength – 530MPa flexural strength provides reliable durability for both anterior and posterior applications
  • Eliminates Porcelain Failure – Monolithic construction removes the weak link of stacked porcelain, preventing chipping and delamination
  • Natural Esthetics – Natural translucency closely mimics tooth structure for seamless integration with existing dentition
  • Long-Term Durability – Monolithic design provides consistent strength throughout the restoration
  • Cost-Effective Solution – Combines premium aesthetics with reliable performance at competitive pricing
  • Conservative Preparation – Minimal tooth reduction requirements preserve valuable tooth structure while maintaining strength
  • Superior Biocompatibility – Lithium disilicate material provides excellent tissue response and patient acceptance
  • Versatile Applications – Suitable for crowns, inlays, onlays, and veneers in various clinical situations
  • Conventional Cementation – Compatible with standard adhesive cementation protocols for simplified delivery
  • Chairside Adjustable – Can be easily adjusted and polished chairside using standard dental burs
  • Predictable Outcomes – Proven material with decades of clinical success and reliable performance

Product Specifications

Single Crown Black
Description IPS e.max monolithic restorations are crafted from a single piece of lithium disilicate glass-ceramic, offering excellent esthetics and durability without layering.
Tooth Shades All 16 VITA shades and 4 bleach shades
Patient Visits (est.) 2
Applications

• Anterior crown
• Bicuspid crown
• Onlays
Materials • Lithium Dicilicate
Benefits Most translucent monolithic option
Records • Traditional or digital impressions
• Impression of prepared teeth
• Opposing and bite registration
• Stump shade
• Shade
Preparation • Chamfer/shoulder prep with 4-8° axial wall taper
• Minimum 1mm chamfer margin of 10-30°
• Minimum 1.5mm occlusal clearance
• Minimum 1.5mm labial and lingual clearance
• No knife edge margins or sharp/right angles
Seating • Clean inside of crown with cleaning solution
• Cement with self-adhesive or conventional cement
Warranty 2 Years
Insurance Codes • D2740 – Crown – porcelain/ceramic substrate
• D6058 – Abutment-supported porcelain/ceramic
• D6065 – Implant-supported porcelain/ceramic
• D2962 – Labial veneer (porcelain laminate) – Laboratory
• D2610-2644 – Inlays & onlays, 1,2,3, or more surfaces
• D6245 – Pontic for a bridge – porcelain/ceramic
• D6740 – Crown for a bridge – porcelain/ceramic
• D6068 – Abutment-supported porcelain/ceramic for a bridge
• D6075 – Implant-supported porcelain/ceramic for a bridge

Video Resources

Mastering Monolithic Zirconia

Fixed Restorations Offerings - Product Comparison

Wear Esthetic Quality Strength Price Tooth Shades Materials
IPS e.max® Monolithic ★★★★ ★★★ 530 mpa $ All • Lithium Dicilicate
IPS e.max® Layered ★★★★ ★★★★★ 400 mpa $$$$ All

• Lithium Dicilicate

• Low fusing Porcelain
PFZ (Porcelain Fused Zirconia) ★★★★ ★★★★★ 250 mpa $$$$ All

• 4Y Yittria Zirconia

• Low fusing Porcelain
TLZ Zirconia with MiYO® ★★★★★ ★★★★ 1100 mpa $ All

• Full Contour 4Y Zirconia

• MiYo Liquid Ceramic
zRc Zirconia ★★★★★ ★★★ 1100 mpa $ All • Full Contour 4Y Zirconia
PFM (Porcelain Fused Metal) ★★★★ ★★★ 200 mpa $$$ All

• Metal of choice

• Opaque

• Layered porcelain
Full Cast Metal ★★★★★ ★★ $ N/A Metal of choice: (non-precious white / noble yellow / high noble yellow)
