NobelProcera®
The NobelProcera Implant Bridge system represents over 12 years of refined full arch restoration technology, offering you a proven direct-to-implant approach that eliminates the complexity and failure risks associated with traditional titanium base systems.
With their latest 3.0 iteration, Nobel has perfected a cement-free delivery protocol using precision-milled zirconia or titanium frameworks that engage directly to your implants through proprietary angulated screw channel technology, providing up to 55 degrees of restorative freedom when combined with their multi-unit prosthetic screws.
The system's flexibility allows us to fabricate restorations in multiple design configurations—from full-contour to cut-back styles—using high-end zirconia in 10 precisely matched VITA shades, while their preload engineering philosophy ensures predictable long-term stability through mechanical retention rather than cement dependence.
Clinical Benefits: NobelProcera Implant Bridge
Elimination of Common Prosthetic Failures:
- Direct-to-implant interface eliminates titanium base complications, cement failures, and component delamination
- Preload engineering philosophy ensures mechanical retention through controlled screw tension rather than unpredictable adhesive bonds
- No more catastrophic failures from cracked or sheared titanium cylinders that compromise entire restorations
Superior Restorative Freedom:
- Up to 55° total angulation correction combining multi-unit abutment positioning with prosthetic screw angulation
- Addresses challenging implant positions without compromising structural integrity or requiring extensive surgical correction
- 25% smaller screw access holes improve esthetics while maintaining strength through optimized material distribution
Streamlined Clinical Delivery:
- Cement-free protocol eliminates cleanup procedures, tissue irritation, and peri-implant complications from cement retention
- Press-fit insert system with audible confirmation ensures proper seating and eliminates guesswork during delivery
- Proprietary Omnigrip instrumentation provides precise torque control with specialized drivers for different connection types
Enhanced Esthetic Outcomes:
- Multiple design configurations (full-contour, cut-back, thimble, framework) allow customized aesthetic approaches
- Smaller, optimally positioned screw channels maintain occlusal and facial esthetics without compromising access
Long-term Predictability:
- Retrieval and serviceability advantages of screw retention allow for maintenance without restoration destruction
- Industrial-grade manufacturing precision from proprietary large blanks ensures a consistent passive fit
- Comprehensive warranty support with QR code traceability provides patient confidence and practice protection
Universal Clinical Compatibility:
- Works with Nobel Biocare and other major implant systems for flexible treatment planning
- Accommodates 2-14 unit spans with up to 10 implant support for complex full arch rehabilitations
Product Specifications

| Application | • All, except heavy bruxers • Does not require metal copings • Must use Nobel-compatiblemulti-unit abutments |
| Days In Lab | 12 Days-In-Lab (does not include shipping) Schedule your patient return with our case delivery calculator |
| Substructure | DOCERAM Nacera® Pearl Zirconia |
| Materials | • DOCERAM Nacera®Pearl Zirconia • MiYO® liquid porcelain |
| Process | • Submit flask or duplicate prosthetic • Prototype Try-in • Final |
| Prosthetic Design | FP3 / FP2 / FP1 |
| Minimum vertical space | 10mm |
| No. of patient visits | 3-6 |
| Esthetic Quality | ★★★★★ |
| Wear | ★★★★★ |
| Price | Click here to receive pricing |
NobelProcera®: Frequently Asked Questions
- How is the NobelProcera bridge delivered and serviced at the chair?
- How does NobelProcera compare to ROE's other fixed full-arch options, and what design styles are available?
- What records does ROE need, and how do the records techniques work?
- How do I request pricing for NobelProcera, submit a case, and what support and warranty back the restoration?
Video Resources
Presenting NobelProcera: Full Arch Zirconia
Full Arch Options: Strength Guide
NobelProcera® Records Required for a Full Arch Bridge
The Process and Components for Seating a NobelProcera® Bridge
NobelProcera® – Capturing Records with a Flasking Technique
NobelProcera® Zirconia Implant Bridge
NobelProcera® Intro
NobelProcera® ASC
Full Arch Fixed Offerings - Product Comparison
| Esthetics | Wear | Price | Prosthetic Design | Substructure | Materials | |
|---|---|---|---|---|---|---|
| TLZ-IB Zirconia | ★★★★★ | ★★★★★ | $$$$ | FP3/FP2/FP1 | Full Zirconia | • Full zirconia • MiYO liquid porcelain • Titanium cylinders |
| TLZ-IB w/ Metal Substructure | ★★★★ | ★★★★★ | $$$$$ | FP3 | Titanium | • Full zirconia • MiYO liquid porcelain • Titanium substructure |
| NobelProcera® | ★★★★★ | ★★★★★ | $$$$ | FP3/FP2/FP1 | DOCERAM Nacera Pearl Zirconia | • DOCERAM Nacera Pearl Zirconia • MiYO liquid porcelain |
| G-CAM Graphenano | ★★★★ | ★★★ | $$ | FP3/FP2/FP1 | n/a | • Graphene nanoreinforced biopolymer G-CAM disc |
