FabCure 2 – 3D Printing Post-Curing Unit
With the advent of newer, more efficient, reliable 3D printing technology dental practices have started considering the business impact of in-office 3D printing. Practice benefits can include accuracy and detail, increased speed of case turnaround, greater versatility, enhanced customization, and reduced external costs.
This page highlights the FabCure 2, a core piece of Shining3D equipment needed to successfully establish 3D printing in-practice.
ROE Dental Laboratory is an authorized distributor of the Shining3D.
FabCure 2 – 3D Printing Post-Curing Unit
The FabCure 2 is Shining 3D’s latest professional post-curing solution tailored for dental 3D printing. As an upgraded version of the original FabCure, it delivers enhanced curing precision and capacity in a compact footprint.
At the core of the FabCure 2 is an array of 30 multi-directional 70W LEDs that emit intense 40mW/cm2 UV light for rapid curing of prints in minutes. The integrated ceramic heating module swiftly heats the spacious internal chamber up to 60°C to not only smooth and refine the printed model’s appearance, but more critically, enhance its durability and resilience.
The durable construction stands up to professional use. By automating high-quality post-processing, the FabCure 2 enables dental practices to improve workflow, quality control, and cost-efficiency. It balances premium curing capabilities in a streamlined 11.4 x 11.4 x 14.5 inch frame weighing just 10.5 kg, and brings next-level dental curing technology within reach.
Design & Operation
The FabCure 2 is purpose-built as a final stage post-curing device for dental applications that prioritizes user safety with thoughtful design features. These smart safety solutions allow for safe, professional operation.
- Double-layered door securely contains heat and UV light inside the curing chamber.
- Engineering plastics with low thermal conductivity line the interior to prevent burns.
- Intuitive controls centered around an OLED screen and tactile knob for smooth, user-friendly interaction. The streamlined menu structure and interface enable simple on-device operation.
- Integrated Wi-Fi connects to the cloud for regular over-the-air updates to firmware, configurations, and the material library enabling the cure unit to be constantly synchronized with Shining 3D to deliver optimized, cutting-edge curing parameters.
The automated FabCure 2 delivers reliable, high-quality post-processing tailored for the unique demands of dental 3D printing.
One Year Warranty. Estimated Shipping 2 Weeks.
FabCure 2 Technical Specifications
| Specification | Details |
|---|---|
| Dimensions (W x D x H) | 290mm x 290mm x 367.5mm |
| Weight | 10.5kg |
| Curing Volume | Φ210mm H180mm |
| Operating Temperature | 10~30°C |
| Max. Curing Temperature | 60°C |
| Light Source | UV LED |
| Wavelength | 385nm~405nm |
| LED Power | 70W |
| Power | AC 100-240V, 150W |
| Interface | Wi-Fi |
| Purchase | Click Here |
